Impulse Water Turbine / Pelton Hydro Turbine / Pelton Water Turbine
for high water head renewable energy
The Pelton turbine is widely used in hydropower station with the
heads from 80-1600m.
Pelton turbine is consisted of runner, turbine case, nozzles
assembly, inlet pipe, deflector etc. The runner is assembled in the
shaft of the generator, torque transmission by ping.
lt utilizes the dynamic power of high pressure water flow to rotate
the runner and force the rotor work, The centre line of the jet is
in the same plane as the runner while rotating.
Pelton turbine has the advantages of compact construction, stable
running and easy operation. Normally, Small pelton turbine always
arranged with horizontal shaft and one or two nozzles, Medium size
and larger Pelton turbines are most often arranged with vertical
shaft, and equip four or six nozzles to obtain more power.
1. Water head: 80m -- 1000m
2. Power: 0.5MW --- 20MW
3. Frequency: 50hz / 60hz
4. Generator Output voltage: 400V, 3.3KV, 6.3KV, or 10.5KV AC three
If you are interested in the Pelton turbine, you should send some
key parameters (such as net head, flow discharge, unit number,
frequency, voltage) in inquiry.
We can supply pelton turbine generator above 500KW, supply the
runner with Forge and CNC machine, or runner with cast abrading
machine for your require.
Horizontal pelton turbine with one /two nozzles
Vertical pelton turbine with four nozzles
80m -- 1000m.
0.5MW -- 20MW
R unner material
Stainless steel (0Cr13Ni4Mo)
Cast machine/Forge + CNC machine
AC Synchronous generator
Governor, Inlet Valve, unit side panel, excitation system
